Exploring and (minimally) recreating Axum

Introduction

Hi! In this article we will try to understand fully how Axum works at the base level, as well as discussing some of the design choices and overall architecture. We will also learn a bit about how it works in practice by writing our own little mini-Axum (the Axum equivalent of Tokio's mini-Redis, if you will).

Our mini-Axum will, by the end of the article, be able to do the following:

If you just want to check out the MVP I've made for this article, you can do that here. However, I would suggest reading the article beforehand as it is likely to provide some much needed clarity on some aspects of the implementation.

This will be the first post in what will hopefully be a series of posts where we explore the internals of different crates and understanding how they work, and hopefully becoming better engineers in the process and have some lessons that we can take away to things that we're all working on. No promises, though!

While an attempt will be made to create high quality code where possible and the code does compile (I wrote all of it by hand!), do bear in mind that some of the code is quite experimental and as such you may come across some caveats should you decide to run some personal experimentation yourself. An effort has been made to record them at the end of the article.

Without further ado, let's get into it! Be prepared - this is a relatively long read.

What is Axum?

Axum is a HTTP web framework by the Tokio team, who are currently maintaining a non-trivial amount of crates related to the async Rust ecosystem.

Its primary objective is to be modular, flexible and easy to use. It requires no macros, using purely function pointers as the handlers. You can declaratively parse requests using extractors (we'll get into this later), with simple and predictable error handling. You can also additionally generate responses with minimal boilerplate.

One thing that sets Axum apart from other frameworks is that it has, by default, full compatibility with the tower crate and ecosystem. This allows axum to be much leaner in terms of not needing to re-implement a full middleware system itself.

It is currently split into a few crates:

This is par the course for most relatively large Rust codebases: crates are split by domain or purpose, which reduces compile time (via reducing bloat) and allows core crates to be much more lean.

How does Axum work under the hood?

Before we actually start building anything, let's have a quick look at how the sausage is made, so to speak. We'll discuss all the core components and how they contribute to the Axum framework.

Hyper & Tower as the core of Axum

Axum, for the most part, is primarily a thin layer over hyper and tower. Tower is essentially a library for creating robust clients and servers that uses functional composition as its core design pattern to be process requests and return a response. By using tower, axum can create manipulate its services to be as composable as possible by allowing many different forms of service layering (Route, Router, MethodRouter... the list goes on).

Of course, the pipeline operations are primarily arbitrary and can do essentially whatever you want. In this case however, Axum takes in what you could essentially consider a Vec<u8> (a byte array), parses data from the request via the extractor pattern, then returns a type-compliant response.

Axum additionally relies upon hyper, a battle-tested Rust HTTP framework library for creating clients and servers. Using hyper allows Axum to not need to manually parse HTTP requests. In production, it's important to keep crates with differing purposes apart - not only does it allow for better abstractions down the road, it also reduces compile time.

Routing

Generally speaking, routing in Axum on the user end is quite simple. You can have routes like this that require zero macro usage:

Router::new().route("/", get(hello_world)).route("/echo", post(echo_message))

Essentially, how this works is that using type wizardry and function pointers you can create route handlers where users can insert an arbitrary number of arguments that implement a given trait into the arguments (which parse data from a given request body/headers), and as long as the return type resolves to a HTTP response, you should be good to go.

From the internal codebase, this is what it roughly looks like:


// https://github.com/tokio-rs/axum/blob/main/axum/src/routing/mod.rs#L71
impl<S> Router<S> {
	// .. other methods
    pub fn route(self, path: &str, method_router: MethodRouter<S>) -> Self {
        tap_inner!(self, mut this => {
            panic_on_err!(this.path_router.route(path, method_router));
        })
    }
}

// https://github.com/tokio-rs/axum/blob/main/axum/src/routing/method_routing.rs#L547
pub struct MethodRouter<S = (), E = Infallible> {
    get: MethodEndpoint<S, E>,
    head: MethodEndpoint<S, E>,
    delete: MethodEndpoint<S, E>,
    options: MethodEndpoint<S, E>,
    patch: MethodEndpoint<S, E>,
    post: MethodEndpoint<S, E>,
    put: MethodEndpoint<S, E>,
    trace: MethodEndpoint<S, E>,
    connect: MethodEndpoint<S, E>,
    fallback: Fallback<S, E>,
    allow_header: AllowHeader,
}

On top of this, some methods are also provided to allow tower services to be created from this router type. Conveniently, there is also a method that allows for calling with state (depending on what the state is, basically):


// https://github.com/tokio-rs/axum/blob/main/axum/src/routing/method_routing.rs#L1286
impl<B, E> Service<Request<B>> for MethodRouter<(), E>
where
    B: HttpBody<Data = Bytes> + Send + 'static,
    B::Error: Into<BoxError>,
{
    type Response = Response;
    type Error = E;
    type Future = RouteFuture<E>;

    // required method for tower services
    // as axum doesn't need to handle this manually, this can typically
    // be safely ignored
    #[inline]
    fn poll_ready(&mut self, _cx: &mut Context<'_>) -> Poll<Result<(), Self::Error>> {
        Poll::Ready(Ok(()))
    }

    #[inline]
    fn call(&mut self, req: Request<B>) -> Self::Future {
        let req = req.map(Body::new);
        self.call_with_state(req, ())
    }
}

Essentially, the method router will chain the routes together and try to find which one matches the request and invoke the relevant service. You can see below that a declarative macro has been set up to do exactly this:


// https://github.com/tokio-rs/axum/blob/main/axum/src/routing/method_routing.rs#L1118
impl<S, E> MethodRouter<S, E> {
	// .. other methods

    pub(crate) fn call_with_state(&self, req: Request, state: S) -> RouteFuture<E> {
        // set up a macro to automate boilerplate generation
        macro_rules! call {
            (
                $req:expr,
                $method_variant:ident,
                $svc:expr
            ) => {
                if *req.method() == Method::$method_variant {
                    match $svc {
                        MethodEndpoint::None => {}
                        MethodEndpoint::Route(route) => {
                            return route.clone().oneshot_inner_owned($req);
                        }
                        MethodEndpoint::BoxedHandler(handler) => {
                            let route = handler.clone().into_route(state);
                            return route.oneshot_inner_owned($req);
                        }
                    }
                }
            };
        }

        // written with a pattern match like this to ensure we call all routes
        let Self {
            get,
            head,
            delete,
            options,
            patch,
            post,
            put,
            trace,
            connect,
            fallback,
            allow_header,
        } = self;

        call!(req, HEAD, head);
        call!(req, HEAD, get);
        call!(req, GET, get);
        call!(req, POST, post);
        call!(req, OPTIONS, options);
        call!(req, PATCH, patch);
        call!(req, PUT, put);
        call!(req, DELETE, delete);
        call!(req, TRACE, trace);
        call!(req, CONNECT, connect);

        let future = fallback.clone().call_with_state(req, state);

        match allow_header {
            AllowHeader::None => future.allow_header(Bytes::new()),
            AllowHeader::Skip => future,
            AllowHeader::Bytes(allow_header) => future.allow_header(allow_header.clone().freeze()),
	        }
	    }
	}
}

From the above, you can see that essentially it just makes a method router that allows for several methods. On receiving a request, it will then try to go through each HTTP request method and check for a match (and call the function pointer if it does match). See the below for an example of how this looks like on the user end:


use axum::{Router, routing::{get, post}};

Router::new().route("/",
    // you can see here the handlers are essentially chained here
	get(hello_world).post(echo_message)
)

Axum uses several macros to be able to generate all the code for all of the given request methods without taking up what would otherwise be an egregious amount of boilerplate. While this does increase compile time slightly, I would argue that it actually makes sense to use macros here given that a lot of the code is very repetitive and there's no real justification otherwise to not use macros (let's face it, would you want all of that boilerplate in your library?).

In terms of matching routes, Axum primarily uses its own router. However, for path routing it leverages matchit which is a high-performance, zero-copy URL router. Primarily speaking, the value from this is that it lets matchit handle the URL parameters rather than trying to re-implement the same thing in Axum.

Extractors

One of the core principles of Axum (and in fact a lot of other web frameworks) is that they make heavy use of the extractor pattern to be able to create ergonomic DX for routing. If you're interested in a full video talk, Rob Ede from Kraken has a great talk on exactly this.

In practice, extractors in Axum look like this:


use axum::Json;

async fn do_something(Json(json): Json<serde_json::Value>) -> &'static str {
	// ...
}

In terms of how extractors work, a basic implementation would look something like this:

// a mock trait to illustrate a type that can be derived from a byte array
trait FromRequest;

// a mock trait to illustrate a handler
trait Handler;

// a mock trait to illustrate a compliant return type
trait Response;

impl<T, F, R> Handler for Fn(T) -> F where
	T: FromRequest,
	F: std::future::Future<Output = R>,
	R: Response
	{
	// .. your methods and whatnot go here
}

This is of course pseudo-code, but you get the idea. You write a function pointer that takes one or more types that implements FromRequest (ie it can be derived from a request), processes it and returns a type that implements Response. Nothing too crazy. Of course, this does lead to a lot of boilerplate, which has evidently led to the use of another declarative macro, named simply (or perhaps amusingly) all_the_tuples:


// https://github.com/tokio-rs/axum/blob/main/axum-core/src/extract/tuple.rs#L74
all_the_tuples!(impl_from_request);

Recreating Axum

Alright, so onto the fun part: recreating Axum. Get ready, because there's going to be a lot of information to digest. If you're re-creating this step-by-step, feel free to take breaks. I know I would.

To start, we're going to create our new project:


cargo init mini-axum
cd mini-axum

Next, we'll add our dependencies. Cue the long list of dependencies!


cargo add bytes futures http http-body-util hyper hyper-util \
serde serde-json tokio tower -F hyper/server,hyper-util/full,serde/derive,\
tokio/net,tower/util

What did we just add?

Let's get started!

Creating our router/service

The first step on our journey will be creating the router/service itself. While I'd love to get into parsing HTTP manually, that itself could probably an article on its own - which is why we'll be leveraging hyper, a battle-tested library that powers several frameworks like Axum (of course!) and Rocket.

To be able to use hyper as a web server, we need to write a type that implements the hyper::service::Service trait - so we'll do exactly that. For now, our Router type is going to be a unit struct - we'll fill it out later.


use hyper::{body::Incoming, service::Service as HyperService};
use http::{Response, Request};
use http_body_util::Full;
use bytes::Bytes;

#[derive(Clone, Default)]
pub struct Router;

impl HyperService<Request<Incoming>> for Router
{
    type Response = Response<Full<Bytes>>;
    type Error = hyper::Error;
    type Future = Pin<Box<dyn Future<Output = Result<Self::Response, Self::Error>> + Send>>;

    fn call(&self, req: Request<Incoming>) -> Self::Future {
        Box::pin(async move { Ok(Response::builder().body(Full::new(Bytes::from("Hello world!"))))
        })
    }
}

As you can see, nothing too crazy. We return a box-pinned future (or a BoxFuture) that contains a hyper response.

The next thing to do is to create the Service struct by attaching together a TcpListener and our router (we'll assume that the user instantiates their own TcpListener).


pub struct Service {
    tcp: TcpListener,
    router: Router,
}

impl Service {
    pub fn new(tcp: TcpListener, router: Router) -> Self {
        Self { tcp, router }
    }

    async fn run(self) -> Result<(), Box<dyn std::error::Error>> {
        loop {
            let (stream, _) = self.tcp.accept().await?;
            let io = TokioIo::new(stream);

            let rtr = self.router.clone();
            tokio::task::spawn(async move {
                if let Err(err) = http1::Builder::new().serve_connection(io, rtr).await {
                    eprintln!("Error serving connection: {:?}", err);
                }
            });
        }
    }
}

Additionally, the Axum implementation of this actually also implements IntoFuture, allowing it to simply be awaited rather than needing to do anything else as this trait allows it to be turned into a future.


impl<S> IntoFuture for Service<S>
where
    S: Clone + Send + Sync + 'static,
{
    type Output = Result<(), Box<dyn std::error::Error>>;
    type IntoFuture = Pin<Box<dyn Future<Output = Self::Output> + Send>>;
    fn into_future(self) -> Self::IntoFuture {
        Box::pin(self.run())
    }
}

Now to actually try out our thing we just made. Create a new examples folder in your project root, then create a file called basic.rs - and put this code in:


use mini_axum::{Router, Service};
use serde_json::{Value, json};
use tokio::net::TcpListener;

#[tokio::main]
async fn main() {
    let rtr = Router;
    let tcp = TcpListener::bind("127.0.0.1:9999")
        .await
        .expect("to be able to bind to localhost port 9999");

    let svc = Service::new(tcp, rtr);

    svc.await.unwrap();
}

Now if you run cargo run --example basic then visit localhost:9999 in your browser, you should see "Hello world!" as the result. Your browser will additionally expect to be able to fetch a favicon, but that can be safely ignored as backend web servers tend to not need those unless you're serving HTML from your router.

Response types

Before we can create any endpoints, we should probably define a response type. While hyper's response type isn't particularly verbose, I would prefer to not have to write it over and over again as an end user.

Below is a short and simple example of this: we write a trait that allows types to be turned into our MiniResponse type, which then implements a method to turn it into a Hyper response.


use bytes::Bytes;
use http::{StatusCode, Response};
use http_body_util::Full;
use bytes::Bytes;

pub trait IntoMiniResponse {
    fn into_response(self) -> MiniResponse;
}

pub struct MiniResponse {
    code: StatusCode,
    content_type: String,
    bytes: Bytes,
}

impl MiniResponse {
    fn new(code: StatusCode, content_type: &str, bytes: Bytes) -> Self {
        Self {
            code,
            content_type: content_type.to_string(),
            bytes,
        }
    }

    pub fn hyper_response(self) -> Response<Full<Bytes>> {
        Response::builder()
            .status(self.code)
            .header("Content-Type", self.content_type)
            .body(Full::new(self.bytes))
            .unwrap()
    }
}

The rest of the work on this is primarily just writing IntoMiniResponse implementations for however many types you want to do it for. Here is one I wrote for returning JSON, as well as plain strings:


use serde::{Deserialize, Serialize};
use http::StatusCode;

#[derive(Deserialize, Serialize)]
pub struct Json<T>(pub T);

impl<T> IntoMiniResponse for (StatusCode, Json<T>)
where
    T: Serialize,
{
    fn into_response(self) -> MiniResponse {
        let (code, bytes) = self;
        let bytes = Bytes::from(serde_json::to_vec(&bytes.0).unwrap());

        MiniResponse::new(code, "application/json", bytes)
    }
}

impl<T> IntoMiniResponse for Json<T>
where
    T: Serialize,
{
    fn into_response(self) -> MiniResponse {
        let bytes = Bytes::from(serde_json::to_vec(&self.0).unwrap());

        MiniResponse::new(StatusCode::OK, "application/json", bytes)
    }
}


impl IntoMiniResponse for String {
    fn into_response(self) -> MiniResponse {
        let bytes = Bytes::from(&self);

        MiniResponse::new(StatusCode::OK, "text/plain", bytes)
    }
}

Since we own the IntoMiniResponse trait, we can also implement it for Result<T, E>:


impl<T, E> IntoMiniResponse for Result<T, E>
where
    T: IntoMiniResponse,
    E: IntoMiniResponse,
{
    fn into_response(self) -> MiniResponse {
        match self {
            Ok(res) => res.into_response(),
            Err(err) => err.into_response(),
        }
    }
}

Technically, we can't actually do anything useful with this yet. However when we get into writing our endpoints, we will need to have this functionality set up already as it'll be part of a required trait bound.

Creating Axum-style endpoints

Here is where it starts to get a bit tricky. Buckle up!

As you probably already know, Axum takes function pointers as inputs for route handlers. The way this is managed is through layers of trait indirection. By converting your function pointers into structs, you can then ensure you don't get compiler errors from trait trickery as your types basically resolve to a concrete type which you can then serve from your router.

The below struct essentially represents a handler, with the input and state types converted to PhantomData, a zero-size value that can be used to essentially pretend that we have ownership of a type when nothing exists there.


pub struct IntoHandlerStruct<H, T, S> {
    inner: H,
	  state: S,
    _tytypes: PhantomData<T>,
}

pub trait IntoHandler<T, S>: Sized {
    fn into_handler(self, state: S) -> IntoHandlerStruct<Self, T, S>;
}

The next thing to do is to implement our new trait for F - that is to say, a function pointer that returns a future wrapping our response type:


impl<F, Fut, I, S> IntoHandler<(), S> for F
where
    F: Fn() -> Fut + Clone + Send + Sync + 'static,
    Fut: Future<Output = I> + Send + 'static,
    I: IntoMiniResponse,
{
    fn into_handler(self, state: S) -> IntoHandlerStruct<Self, (), S> {
        IntoHandlerStruct {
            inner: self,
            state,
            _tytypes: PhantomData,
        }
    }
}

There are a couple of things to note here:

Once done, we then need to implement the tower::Service trait for IntoHandlerStruct which will allow it to be used with the tower ecosystem. Perfect for a composable router. Below are some notes on the type signatures so you don't get lost:


impl<F, Fut, S, I> tower::Service<Request<Incoming>> for IntoHandlerStruct<F, (), S>
where
    F: Fn() -> Fut + Clone + Send + Sync + 'static,
    Fut: Future<Output = I> + Send + 'static,
    I: IntoMiniResponse,
    S: Clone + Send + Sync + 'static,
{
    type Error = hyper::Error;
    type Response = Response<Full<Bytes>>;
    type Future = BoxFuture<'static, Result<Self::Response, Self::Error>>;
    fn poll_ready(
        &mut self,
        cx: &mut std::task::Context<'_>,
    ) -> std::task::Poll<Result<(), Self::Error>> {
        std::task::Poll::Ready(Ok(()))
    }
    fn call(&mut self, _req: Request<Incoming>) -> Self::Future {
        let thing = self.inner.clone();

        Box::pin(async move { Ok((thing)().await.into_response().hyper_response()) })
    }
}

Next, we are going to use a struct called tower::util::BoxCloneSyncService - essentially, a generic boxed service that also implements Clone and Sync. This allows you to share and send it across threads, which is great for us as we're working in mostly a fully async scenario. Here is the type signature we'll be using:

type DynService = BoxCloneSyncService<Request<Incoming>, Response<Full<Bytes>>, hyper::Error>;

Now that we've defined our dynamic service type, we're going to use it in our router. We will also additionally define the S generic which will be our shared state. For now though, we will leave our router stateless and come back to it as we'll be covering it in another section later.


use std::sync::Arc;

// Note: Technically, if your RwLock ever needs to cross an await point, you should use tokio's RwLock.
// However, in our case, it doesn't, so we should be fine here.
use std::sync::RwLock;

#[derive(Clone, Default)]
pub struct Router<S = ()> {
    pub inner: Arc<RwLock<HashMap<String, DynService>>>,
    state: S
}

// stateless router - we'll come back to this!
impl Router<()> {
	fn new() -> Self {
	    Self {
            inner: Arc::new(RwLock::new(HashMap::new())),
            state: ()
        }
	}
}

In terms of adding a function to add a route, we need to set a pretty heavy amount of trait bounds. You can see the length of the type signature below is not particularly easy on the eyes:


impl<S> Router<S>
where
    S: Clone + Send + Sync + 'static,
{
    pub fn route<T, E>(self, route: &str, endpoint: E) -> Self
    where
        T: 'static + Sync + Send,
        E: IntoHandler<T, S> + Clone + Send + Sync + 'static,
        IntoHandlerStruct<E, T, S>: tower::Service<
                Request<Incoming>,
                Response = Response<Full<Bytes>>,
                Error = hyper::Error,
                Future = Pin<
                    Box<dyn Future<Output = Result<Response<Full<Bytes>>, hyper::Error>> + Send>,
                >,
            > + 'static,
    {
        let endpoint = endpoint.into_handler(self.state.clone());

        self.inner
            .write()
            .unwrap()
            .insert(route.to_string(), BoxCloneSyncService::new(endpoint));

        self
    }
}

The reason why we need the trait bounds in the first place is because we need to ensure that T is thread-safe (although we use collections of tuples for inputs, a tuple of any amount of elements can be considered 1 type). We also need to ensure that the input type itself also implements IntoHandler as we need to convert the function pointers into IntoHandlerStructs.

What might be slightly more confusing however is setting trait bounds on IntoHandlerStruct<E, T, S>. While we know that this struct implements tower::Service, the compiler is unable to infer this by itself. Hence, we need to put the full type signature for the kind of tower::Service trait bounds we're using.

You may have noticed that while we're taking IntoHandler<T, S> for our route function, the type we're storing actually implements Endpoint<S>. While we know that the return type of IntoHandler::into_handler() returns IntoHandlerStruct<E, T, S>, the compiler doesn't - so we need to make sure we declare that in our function.

We will also additionally need to go back to our impl<S> Service<Request<Incoming>> for Router<S> block and make some changes.


impl<S> Service<Request<Incoming>> for Router<S>
where
    S: Clone + Send + Sync + 'static,
{
    type Response = Response<Full<Bytes>>;
    type Error = hyper::Error;
    type Future = Pin<Box<dyn Future<Output = Result<Self::Response, Self::Error>> + Send>>;

    fn call(&self, req: Request<Incoming>) -> Self::Future {
	    // get the URI path and router
        let rdr = self.inner.read().unwrap();
        let path = req.uri().path();

		// clone state so we can put it in our router
        let state = self.state.clone();
        println!("Path: {path}");

		// if a path is found, run the resulting handler
		// if not, return 404
        if let Some(func) = rdr.get(req.uri().path()) {
            let mut func = func.clone();
            Box::pin(async move { func.call(req).await })
        } else {
            Box::pin(async move {
                Ok((StatusCode::NOT_FOUND, "Not found")
                    .into_response()
                    .hyper_response())
            })
        }
    }
}

Finally, let's go back to our basic.rs example we wrote earlier, and change it a bit. We will add a handler function that returns a JSON message and add it as a route in our router.


use hyper::StatusCode;
use mini_axum::{
    Router, Service,
    response::{IntoMiniResponse, Json},
};
use serde_json::{Value, json};
use tokio::net::TcpListener;

#[tokio::main]
async fn main() {
    let rtr = Router::new()
        .route("/", hello_world);

    let tcp = TcpListener::bind("127.0.0.1:9999")
        .await
        .expect("to be able to bind to localhost port 9999");

    let svc = Service::new(tcp, rtr);

    svc.await.unwrap();
}

pub async fn hello_world() -> impl IntoMiniResponse {
    let json = json!({"message": "Hello world!"});

    (StatusCode::OK, Json(json))
}

Now this looks a bit more like the axum we're all used to!

If you run cargo run --example basic again and try visiting localhost:9999 in your browser, you should get {"message": "Hello world!"} as a response with an option to prettify the returned JSON.

Writing our own Axum-style extractor system

The process of using extractors is (in theory) relatively simple: you just add them as arguments to your handler, and it just works. For example (using the official Axum library):


use axum::Json;

async fn echo_message(Json(json): Json<serde_json::Value>) -> Json<serde_json::Value> {
	Json(json)
}

Not a particularly complex handler, mind you, but it should work if you were to insert this as a handler into an Axum server.

On the other hand, implementing extractors can be significantly more painful and tricky if you're not sure how to manipulate the type system. If you visited the extractor talk video I linked earlier, you probably have a good idea of what we're about to do.

The code for this part essentially relies upon two traits - FromRequest and FromRequestParts (we'll use the same naming here as there's no reason to deviate):


use http::Request;
use hyper::body::Incoming;

pub trait FromRequest<S>: Send + Sync {
    fn from_request(req: Request<Incoming>, state: &S) -> impl Future<Output = Self> + Send;
}

pub trait FromRequestParts<S>: Send + Sync {
    fn from_request_parts(
        req: http::request::Parts,
        state: &S,
    ) -> impl Future<Output = Self> + Send;
}

We will also want to implement FromRequest and FromRequestParts for types of our choice. For the demo we'll use JSON and State as State is basically already existent in our framework no matter what, and we've already implemented a JSON response.


impl<S, T> FromRequest<S> for Json<T>
where
    T: for<'a> serde::Deserialize<'a> + Send + Sync,
    S: Clone + Send + Sync,
{
    async fn from_request(req: Request<Incoming>, _state: &S) -> Self {
        let (_, body) = req.into_parts();
        let body: Vec<u8> = body.collect().await.unwrap().to_bytes().to_vec();
        let json: T = serde_json::from_slice(&body).unwrap();

        Json(json)
    }
}

pub struct State<T>(pub T);

impl<S> FromRequestParts<S> for State<S>
where
    S: Clone + Send + Sync,
{
    async fn from_request_parts(_req: Parts, state: &S) -> Self {
        State(state.to_owned())
    }
}

impl<S> FromRequest<S> for State<S>
where
    S: Clone + Send + Sync,
{
    async fn from_request(_req: Request<Incoming>, state: &S) -> Self {
        State(state.to_owned())
    }
}

Additionally, to remove code bloat we'll impl FromRequest for tuples of elements where the last element always implements FromRequest, but all other items implement FromRequestParts:


impl<S, T1> FromRequest<S> for (T1,)
where
    T1: FromRequest<S>,
    S: Clone + Send + Sync,
{
    async fn from_request(req: Request<Incoming>, state: &S) -> Self {
        let t1 = T1::from_request(req, &state).await;

        (t1,)
    }
}

impl<S, T1, T2> FromRequest<S> for (T1, T2)
where
    T1: FromRequestParts<S>,
    T2: FromRequest<S>,
    S: Clone + Send + Sync,
{
    async fn from_request(req: Request<Incoming>, state: &S) -> Self {
        let (parts, body) = req.into_parts();
        let t1 = T1::from_request_parts(parts.clone(), &state).await;

        let req = Request::from_parts(parts, body);
        let t2 = T2::from_request(req, &state).await;

        (t1, t2)
    }
}

Notes:

Now to write the trait magic that makes it all work!

While the axum repository does use macros to minimise the amount of toil required to maintain the code for this, we will be implementing a much more minimal version to illustrate the point as after more than 1 or 2 arguments, it's mostly just copy and pasting.

As mentioned before when we wrote our original IntoHandler block, we implemented it for a function that essentially has no arguments. Here is the impl block for reference so you don't have to go halfway back up the blog post again:


impl<F, Fut, I, S> IntoHandler<(), S> for F
where
    F: Fn() -> Fut + Clone + Send + Sync + 'static,
    Fut: Future<Output = I> + Send + 'static,
    I: IntoMiniResponse,
{
    fn into_handler(self) -> IntoHandlerStruct<Self, (), S> {
        IntoHandlerStruct {
            inner: self,
            _tystate: PhantomData,
            _tytypes: PhantomData,
        }
    }
}

Now we'll be implementing it for a function pointer that does take arguments. If you're following along, it would be prudent to check that the first type of IntoHandler for your implementation uses a comma to turn the type into a tuple - if you use (T1) it will assume it's just any old generic and it won't compile.


// turn the function into a handler
impl<F, Fut, I, S, T1> IntoHandler<(T1,), S> for F
where
    F: Fn(T1) -> Fut + Clone + Send + Sync + 'static,
    Fut: Future<Output = I> + Send + 'static,
    I: IntoMiniResponse,
    T1: FromRequest<S> + Send + 'static,
{
    fn into_handler(self) -> IntoHandlerStruct<Self, (T1,), S> {
        IntoHandlerStruct {
            inner: self,
            _tystate: PhantomData,
            _tytypes: PhantomData,
        }
    }
}

impl<H, Fut, S, I, T1> tower::Service<Request<Incoming>> for IntoHandlerStruct<H, (T1,), S>
where
    H: Fn(T1) -> Fut + Clone + Send + Sync + 'static,
    Fut: Future<Output = I> + Send + 'static,
    I: IntoMiniResponse,
    T1: FromRequest<S> + Send + 'static,
    S: Send + Clone + Sync + 'static,
{
    type Error = hyper::Error;
    type Response = Response<Full<Bytes>>;
    type Future = BoxFuture<'static, Result<Self::Response, Self::Error>>;
    fn poll_ready(
        &mut self,
        cx: &mut std::task::Context<'_>,
    ) -> std::task::Poll<Result<(), Self::Error>> {
        std::task::Poll::Ready(Ok(()))
    }
    fn call(&mut self, req: Request<Incoming>) -> Self::Future {
        let thing = self.inner.clone();
        let state = self.state.clone();

        Box::pin(async move {
            let (t1) = T1::from_request(req, &state).await;
            Ok((thing)(t1).await.into_response().hyper_response())
        })
    }
}

While the generics are are somewhat intimidating, it's also mostly the same as the last time we impl'd Endpoint<S> and IntoHandler<T, S> except we are now adding trait generics that represent arguments to be taken by the function handler.

For functions that take two arguments, we need to ensure that the first argument implements FromRequestParts rather than FromRequest as we need to ensure the request body doesn't actually get consumed before the last argument consumes it. Below is what this would look like:


impl<F, Fut, I, S, T1, T2> IntoHandler<(T1, T2), S> for F
where
    F: Fn(T1, T2) -> Fut + Clone + Send + Sync + 'static,
    Fut: Future<Output = I> + Send + 'static,
    I: IntoMiniResponse,
    T1: FromRequestParts<S> + Send + 'static,
    T2: FromRequest<S> + Send + 'static,
{
    fn into_handler(self) -> IntoHandlerStruct<Self, (T1, T2), S> {
        IntoHandlerStruct {
            inner: self,
            _tystate: PhantomData,
            _tytypes: PhantomData,
        }
    }
}

impl<H, Fut, S, I, T1, T2> tower::Service<Request<Incoming>> for IntoHandlerStruct<H, (T1, T2), S>
where
    H: Fn(T1, T2) -> Fut + Clone + Send + Sync + 'static,
    Fut: Future<Output = I> + Send + 'static,
    I: IntoMiniResponse,
    T2: FromRequest<S> + Send + 'static,
    T1: FromRequestParts<S> + Send + 'static,
    S: Send + Clone + Sync + 'static,
{
    type Error = hyper::Error;
    type Response = Response<Full<Bytes>>;
    type Future = BoxFuture<'static, Result<Self::Response, Self::Error>>;
    fn poll_ready(
        &mut self,
        cx: &mut std::task::Context<'_>,
    ) -> std::task::Poll<Result<(), Self::Error>> {
        std::task::Poll::Ready(Ok(()))
    }
    fn call(&mut self, req: Request<Incoming>) -> Self::Future {
        let thing = self.inner.clone();
        let state = self.state.clone();

        Box::pin(async move {
            let (t1, t2) = <(T1, T2)>::from_request(req, &state).await;
            Ok((thing)(t1, t2).await.into_response().hyper_response())
        })
    }
}

For each tuple interpolation after this one, it's pretty much the same: just add the trait generics on and do the thing.

Adding middleware

Now that we've implemented tower::Service<T> for our endpoints, we can now implement middleware for all of our services!

Due to extractors being such a present pattern in Rust frameworks, it is generally recommended to use middleware as more of a global add-on rather than using it for things like authz (for example) when you could use extractors instead.

Firstly, we'll create our own middleware layer that logs out the path and request method - then we'll add a layer method to our router.

A simple LogLayer middleware can be created like so that will print the HTTP method and URI, and then call the service:


use http::Request;
use hyper::body::Incoming;
use tower::Service;

#[derive(Clone)]
pub struct LogLayer;

impl<S> tower::Layer<S> for LogLayer {
    type Service = LogService<S>;

    fn layer(&self, inner: S) -> Self::Service {
        LogService { inner }
    }
}

#[derive(Clone)]
pub struct LogService<S> {
    inner: S,
}

impl<S> tower::Service<Request<Incoming>> for LogService<S>
where
    S: Service<Request<Incoming>> + Clone,
{
    type Error = S::Error;
    type Response = S::Response;
    type Future = S::Future;

    fn call(&mut self, req: Request<Incoming>) -> Self::Future {
        let (parts, body) = req.into_parts();
        let req = Request::from_parts(parts.clone(), body);

		println!("{method} {uri}", method = parts.method, uri = parts.uri);

        let mut service = self.inner.clone();

        service.call(req)
    }

    fn poll_ready(
        &mut self,
        cx: &mut std::task::Context<'_>,
    ) -> std::task::Poll<Result<(), Self::Error>> {
        std::task::Poll::Ready(Ok(()))
    }
}

Admittedly, this is not the most ergonomic way to do it, but it works. You may want to read the current limitations of our implementation to explore why this is the case.

Next, to add a layering function for our router. Fortunately, this part is quite simple: we simply iterate over every service in our router, and layer it. To be able to do so requires putting a large amount of trait bounds on our L generic. However, as they primarily relate to the trait bounds of the tower services, you can guess without too much hesitation what exactly the trait bounds will be.


impl Router<S> where S: Clone + Send + Sync + 'static {
    // .. other fns
    pub fn layer<L>(mut self, layer: L) -> Self
    where
        L: Layer<DynService> + Clone + Send + Sync + 'static,
        L::Service: Service<
                Request<Incoming>,
                Response = Response<Full<Bytes>>,
                Error = hyper::Error,
                Future = BoxFuture<'static, Result<Response<Full<Bytes>>, hyper::Error>>,
            > + Clone
            + Send
            + Sync
            + 'static,
        <L::Service as Service<Request<Incoming>>>::Future: Send + 'static,
    {
        let res: HashMap<String, DynService> = self
            .inner
            .write()
            .unwrap()
            .clone()
            .into_iter()
            .map(|(k, v)| {
                let service = ServiceBuilder::new().layer(layer.clone()).service(v);

                (k, BoxCloneSyncService::new(service))
            })
            .collect();

        self.inner = Arc::new(RwLock::new(res));

        self
    }
}

State in Axum

State in Axum can be defined broadly as "some variables that are shared between handlers". In that sense, there are a total of 4 different ways that you can actually apply state to handlers:

Most people will likely opt for the first two options as a lot of the time using closure captures may not be ideal, and task-local variables rely on the task executor actually being able to use task-local variables and is more primarily for things like sharing state with things like IntoResponse implementations.

For reference, here is what an example of using State from an extractor looks like:


use axum::extract::State;
use axum::http::StatusCode;

#[derive(Clone)]
struct MyType;

// code in a function
let router = Router::new()
    .route("/", get(do_something))
    .with_state(MyType);

// our handler
async fn do_something(State(state): State<MyType>) -> StatusCode {
    // .. do something here

    StatusCode::OK
}

Pretty easy, all things considered. You can't change the state type (unless you use FromRef), but it's very ergonomic and mostly self-explanatory.

Of course, as you've probably noticed we have already implemented the first type of state which is built into the router endpoints. However, you can also implement Extension<T> as a layer by doing the following:

Firstly, we'll create the layer type (so we can add it into our router):


struct Extension<T>(pub T);
struct ExtensionService<T, S> { ext: T, inner: S };

impl<S, T> Layer<S> for Extension<T> where T: Clone {
    type Service = ExtensionService<T>;

    fn layer(&self, inner: S) -> Self::Service {
        ExtensionService { ext: self.0.clone(), inner }
    }
}

impl<T, S> tower::Service<Request<Incoming>> for ExtensionService<T, S> where T: Clone, S: Service<Request<Incoming>> {
    type Error = S::Error;
    type Response = S::Response;
    type Future = S::Future;

    fn call(&mut self, mut req: Request<Incoming>) -> Self::Future {
        req.extensions_mut().insert(self.ext);

        let mut service = self.inner.clone();

        service.call(req)
    }

    fn poll_ready(
        &mut self,
        cx: &mut std::task::Context<'_>,
    ) -> std::task::Poll<Result<(), Self::Error>> {
        std::task::Poll::Ready(Ok(()))
    }
}

The second half of this is the FromRequest implementation. Pretty easy.


impl<T, S> FromRequest<S> for Extension<T> {
    async fn from_request(req: Request<Incoming>, state: &S) -> Self {
        let Some(val) = request.extensions.get::<T>() else {
            panic!("Welp, there's nothing here.");
        }

        Self(val)
    }
}

This will allow you to add extensions into your route handlers like so:


use mini_axum::{Extension};

// router code in a function
let rtr = Router::new().layer(Extension("Hello world!".to_string()));

async fn do_something(Extension(ext): Extension<String>) -> String {
    ext
}

Not entirely typesafe mind you as there may be issues with adding the extension data that can cause unwanted behaviour if you use the wrong type, but it's there.

Finishing up

Thanks for reading! I hope this has been somewhat enlightening. This has been an extremely long post and I've spent many hours toiling and trying to understand the magic that makes Axum the framework that it is today, but we have done it. Hopefully, we have become better engineers for doing it. Below are additionally a list of current demo limitations and pitfalls to avoid while recreating the MVP should you decide to do so.

Our current limitations

Of course, the demo we just created isn't without limitations/caveats. Here is a list of them below:

Potential pitfalls to avoid

While writing this article (and therefore the MVP demo), I've had my fair share of compiler persuasion to deal with and thought it might be a good idea to share the things I did wrong so you can avoid them in the future if you are embarking on a journey with a similar level of type trickery:
